baling Chamber | 25” X 30” X 55” (H X W X L) Inches |
bale Size | 15” X 15” (H X W ) |
electric Motor | 25 +2 H.P 3 Phase 1440 Rpm |
body | fabricated 45+12 Mm |
hard Liner Plates | provided ( C 45 ) |
oil Drive | double Pump Syatems |
working Liquid | hydro/enclo-68 (Not In Our Scope) |
no. Of Cylinder | 5 Nos. |
lid Cylinder | 40 Tons (150 Bore X 180 Od X 100 Ram) |
main Cylinder | 100 Tons (220 Bore X 270 Od X 150 Ram) |
side Cylinder | 120 Tons (270 Bore X 320 Od X 160 Ram) |
lock Cylinder | 12 Tons (100 Bore X 115 Od X 65 Ram) |
bale Eject Cylinder | 12 Tons (100 Bore X 115 Od X 65 Ram) |
working Pressure | 3000 Psi |
oil Cooling Systems | provided (2 Tr Ac) |
starter | optional |
idle Cycle Time | 60 -70 Seconds (Approx) |
bale Weight | ms/ss 40 To 70 Kg Depend On Material Density |
oil Tank Capacity | 800 Lts. |
operation Of The Machine | manual Through 3 Levers |
usage/application | automobile Waste, Metal Sharp, Other |
